Mitsubishi 6G72 engine factory workshop and repair manual download
Mitsubishi 6G72 engine factory workshop and repair manual
on PDF can be viewed using free PDF reader like adobe , or foxit or nitro . It is compressed as a zip file which you can extract with 7zip
File size 5 Mb Searchable PDF document with bookmarks.
Manual Contents
BRACKET
INTAKE MANIFOLD PLENUM AND
THROTTLE BODY
CAMSHAFT, ROCKER ARMS
BEARING CAPS
OIL PAN AND OIL PUMP
CRANKSHAFT, FLYWHEEL ANDPISTON AND CONNECTING ROD DRIVE PLATE
ROCKER ARMS AND CAMSHAFTS
CYLINDER HEAD AND VALVES SOHC
CYLINDER HEAD AND VALVES DOHC
SERVICE SPECIFICATIONS
EXHAUST MANIFOLD
SPECIAL TOOLS
GENERAL INFORMATION
THROTTLE BODY
GENERAL SPECIFICATIONS
TIMING BELT SOHC
GENERATOR AND DRIVE BELT
TIMING BELT- DOHC
IGNITION SYSTEM
TORQUE SPECIFICATIONS
INTAKE MANIFOLD AND FUEL PARTS
TURBOCHARGER
About the 6G72 engine
The 6G7 or Cyclone V6 engine is a series of V6 piston engines from Mitsubishi Motors Corporation. Five displacement variants have been produced from 1986 to present day, with both SOHC and DOHC layouts. While MIVEC variable valve timing has also been implemented in some versions. The 2.5 and 3.0 L versions were also available with gasoline direct injection.
The 6G72 was manufactured in three different models which featured SOHC with 12-valves, SOHC with 24-valve, and DOHC with 24-valves. The latest version was used in the Mitsubishi Eclipse GT and Galant. Output in 2004 was 210 hp (157 kW; 213 PS) at 5500 rpm with 278 N·m (205 lbf·ft) of torque at 4000 rpm. In the older version, used in many Chrysler models since 1987 this V6 was a SOHC 12-valve developing 141 hp (105 kW) at 5000 rpm and 172 lb·ft (233 N·m) of torque at 3600 rpm. The Mitsubishi models were with a 3.0 Litre 6G72 engine SOHC 24-valve developing 195 hp (145 kW) at 5000 rpm and 205 lb·ft (278 N·m) of torque at 4000 rpm.For the MIVEC engine output is 201 kW (273 PS; 270 hp) at 6000 and 304 N·m (224 lbf·ft) at 4500.
The SOHC 12-valve for the second generation of Pajero can provid 109kW and 235N·m,the SOHC 24-valve can provid 133kW and 255N·m.
1986-1992 Mitsubishi Debonair
1987–2000 Dodge Caravan/Plymouth Voyager
1988–1989 Chrysler New Yorker
1988–1990 Dodge Raider
1988-1990 Mitsubishi Sigma
1988–1993 Dodge Dynasty
1988–present Mitsubishi Pajero (aka Montero/Shogun) (Except GCC and Oceania now)
1989-1990 Chrysler Town & Country (early 1989 models only)
1989–1995 Plymouth Acclaim/Dodge Spirit/Chrysler Saratoga
1990–1991 Chrysler TC by Maserati
1990–1993 Dodge Daytona
1990–1993 Dodge Ram 50
1990–1995 Chrysler LeBaron
1990–1996 Mitsubishi Mighty Max
1990–1998 Hyundai Sonata
1990–1999 Mitsubishi GTO (aka Mitsubishi 3000GT, Dodge Stealth)
1990–2002 Mitsubishi Diamante
1990–2006 Mitsubishi L200
1991-1996 Dodge Stealth
1991–1996 Mitsubishi Verada (Australia)
1992–1994 Dodge Shadow ES
1992–1994 Dodge Shadow
1993–2001 Mitsubishi Magna (Australia)
1994-2007 Mitsubishi L400(aka Space Gear)
1995-1999 Proton Perdana
1997–2007 Mitsubishi Pajero Sport (aka Montero Sport/aka Challenger in Australia)
1999–2003 Mitsubishi Galant
2000–2005 Mitsubishi Eclipse
2001–2005 Dodge Stratus/Chrysler Sebring Coupe
Mitsubishi 6G72 engine factory workshop and repair manual Download
