Toyota 5L-E engine factory workshop and repair manual
Toyota 5L-E engine factory workshop and repair manual
on PDF can be viewed using PDF reader like adobe , or foxit or nitro . It is compressed as a zip file which you can extract with 7zip
File size 12 Mb
Covers
5L BELT INSTALL
5L COMPONANTS
5L CRANK ANGLE SENSOR
5L DRIVE BELT COMPONANTS
5L ECD SYSTEM DIAGRAM
5L ENGINE COMPONANTS
5L ENGINE REMOVAL
5L ENGINE UNIT COMPONANTS
5L FRONT OIL SEAL INSTALL
5L FRONT OIL SEAL REMOVAL
5L FRONT SEAL COMPONANTS
5L HEAD COMPONANTS
5L HEAD INSTALL
5L HEAD REMOVAL
5L INJECTIOR NOZZLE COMPONANTS
5L INJECTOR PUMP COMPONANTS
5L REAR OIL SEAL COMPONANTS
5L SERVICE SPECS
5L TORQUE SPECS
5L VENTURI COMPONANTS
5L-E ENGINE SUP. RM817E
CAM INSTALL
CAM REMOVAL
ECD SYSTEM
ENGINE TIMING BELT COMPONANTS
ENGINE UNIT DIASSEMBLY
ENGINE UNIT REASSEMBLY
PRESSURE SENSOR
RAR OIL SEAL INSTALL
REAR OIL SEAL REMOVAL
TIMING BELT INSTALL
TIMING BELT REMOVAL
VALVE CLEARANCE ADJUSTMENT
Searchable document with bookmarks.
About the 5L-E engine
The 5L-E is a 3.0 L (2,986 cc) EFI version of the 5L engine. It is the latest member of the L family. It has a bore of 99.5 mm and stroke of 96.0 mm, with a compression ratio of 22.2:1. Output (as fitted to the Hilux is 97 PS (71 kW) at 4,000 rpm with 192 N·m (142 ft·lb) of torque at 2,400 rpm.Power output varies according to fitment. The engine number is found on the top face of the block at the front of the engine.
